Lammina
10 UL
ULTRA LIGHT ALUMINUM TENDERS
Extremely light in weight, small but powerful, designed to delivery performance in style.
Lammina is the first line of marine-grade, aluminum-hull inflatables to reach the U.S. market. The Superlight models, available in lengths 9,5 feet and under, feature a 2,28mm (0.090”) aluminum hull. The rest of the line, available in lengths 10 feet and larger, sports a 3,17mm (0.125”) aluminum hull. The transom thickness on models 8 to 10 feet is 3,17mm (0.125”) and from models 11 to 16 feet is 4,7mm (0.190”). These tough, lightweight and durable aluminum hulls will resist abrasions from rocky shores, coral and sandy beaches. The innovative design of the Lammina series cuts through wakes and chop with far less pounding. The result is an exceptionally dry, stable and superior ride.LAMMINA 10 UL GALLERY
KEY FEATURES
- Large Square Transom Alum. Reinforced Base
- More Payload capacity
- Ultra High Quality Welding
- Reinforced Aluminum Bow Eye with SS Rings
- Reinforced Aluminum Lifting Eyes with SS Rings
- Aluminum Removable Rowing Seat
- ORCA (CSM) Coated Fabric
- Sunbrella Fabric Dinghy Chap Available
- Sunbrella Fabric Boat Cover Available
- Internal Aluminum Plate with Security Lip
- New Chrome Free - Advanced Pretreatment and Powder Coating Technology
- Ultra High Quality Welding
- Reinforced (CSM) Fabric Handles
- Custom Colors Upon Request
- Non-skid Rubber Floor
SPECS
Overall length
10' /3.05m
Overall Beam
5' 6" / 1.68m
Inside Length
7' 2"/2.18m
Inside Beam
2' 8"/ 0.81m
Tube Diameter
17" / 0.43m
Number of Chambers
3
Person Capacity
5
Weight
95lb / 43kg
Recommended HP
8 hp / 6.0kg
Maximum HP
9.9hp / 7.4kg
Shaft length
15" / 38.1cm
RDC Design Category
C
STANDARD EQUIPMENT
Shallow “V” Marine Grade Aluminum HullTransom Knee
Non-Skid Rubber Floor Panels
Plastic External Transom Plate
Aluminum Internal Transom Plate With Security Lip
Aluminum Bow Eye
3 Aluminum Davit Lifting Points
Deck Drain with Plug
Orca (CSM) Five Layer Coated Fabric
Raised Single Rub Rail
Push Push Plastic Non-Corrosive 2 Stage Inflation Valves
1 Front & 2 Side Orca (CSM) Fabric Handles on Tubes
2 Inside Bow Sets of Double Orca (CSM) Fabric Handles on Tubes
2 Inside Stern Double Orca (CSM) Fabric Handles on Tubes
Removable Rowing Seat
Oarlock Base
Telescopic Oars with Aluminum Shaft
Paddle Holders
Hand Pump
Maintenance Kit
Owner's Manual
3 Layers Reinforced Seams
OPTIONAL EQUIPMENT
Tube ChapsBoat Cover
Chock Set
Lammina
10 UL
